14
Technical data
PC
EPDM
PPS
EPDM
PPS
PVDF
PVC or PVDF
EPDM
PVDF
Stainless steel
316Ti
Stainless steel
Nickel-plated
brass
pH/Redox probe
Part Material
Box / seals stainless steel, PPS / EPDM
Cover / seal PC / EPDM
Display module PC / PBT
M12 fixed connector nickel-plated brass
Fixed connector holder stainless steel 1.4404 (316L)
Screws stainless steel
Nut PVC or PVDF
Sensor holder / seal (in
contact with the fluid)
PVDF, stainless steel 1.4571
(316Ti) / EPDM
pH or Redox probe refer to the related manual
Fig. 5 Materials used in the transmitter 8202 (without the probe)
175
210
260
75
111
59
23.8
20
5078
Fig. 6 Dimensions of transmitter 8202 [mm]
English
Type 8202 ELEMENT
