37
Operating and functions
9.7.2. When switching on the device
When the device is switched on or the display module mounted on the electronic module, the display indicates
the software version of the display.
The display then shows the first screen in READ level:
O
P
E
N
L
O
C
K
mV_pH
1423 mV
TempC
23.8 °C
Fig. 35 Display indications when powering on the device
9.8. Read level
mV_pH
1423 mV
TempC
55 °C
mV_pH
1423
mV
18.3 mA
AC1
7.5 mA
AC2
A
1)
1)
1)
First view of the Read level.
Zoom on the value in the
first line.
Zoom on the value in the
second line.
AC1
18.3 mA
AC2
7.5 mA
A
Display of the highest and
lowest values of the physical
quantity chosen
Display of the current
outputs.
Zoom on the value of the
first current output.
Zoom on the value of the
second current output.
TempC
55
°C
Max
1450mV
Min
1200mV
Reset Yes/No
B
B
2)
1)
To choose the process values to be displayed see chap. 9.11.5
2)
The display of the lowest and highest values in the Read level is deactivated by default. To activate the feature and choose
the process values see chap. 9.11.3
English
Type 8202 ELEMENT
