Technical data
6.3.2. General technical data
Pipe diameter DN25 to DN110 (DN15 to DN20 under specific
conditions)
Type of fitting Adapter S022
Nut between the 8202 and the fitting G 1 1/2'' internal thread
Max. fluid temperature
• with a PVDF nut (see also Fig. 2and Fig. 4)
• with a PVC nut (see also Fig. 2 and Fig. 3)
The fluid temperature may be restricted by the probe
used (see the related instruction manual), by the
pressure of the fluid and the material of the adapter
S022
• -20 to +130 °C
• 0 to +50 °C
Max. fluid pressure PN16
The fluid pressure may be restricted by the probe used
(see the related instruction manual), by the temperature
of the fluid and the material of the adapter S022 (see
Fig. 2, Fig. 3 and Fig. 4)
pH measurement
• Measurement range
• Resolution
• Accuracy
• Recommended min. divergence of the pH range
associated to the 4-20 mA signal
• -2 to 16 pH or -580 to +580 mV
• 0.001 pH or 0.1 mV
• ±0.02 pH or 0.5 mV
• 0.5 pH unit or 30 mV (eg: range 6,7 to 7,2 pH or
-20 mV to +10 mV associated to the 4-20 mA
output current)
Redox potential measurement
• Measurement range
• Resolution
• Accuracy
• Recommended min. divergence of the redox potential
range associated to the 4-20 mA signal
• -2000 mV to +2000 mV
• 1 mV
• ±3 mV
• 50 mV (eg: range 1550 to 1600 mV associated to
the 4-20 mA output current)
Temperature measurement
• Measurement range
• Resolution
• Accuracy
• Recommended min. divergence of the temperature
range associated to the 4-20 mA signal
• -40 °C to +130 °C
• 0.1 °C
• ±1 °C
• 10 °C (eg: range 10 to 20 °C associated to the
4-20 mA output current)
Temperature probe Pt1000 integrated in the sensor holder
Temperature compensation • Automatic (integrated Pt1000)
• Reference temperature = 25°C
