Burkert 8202 ELEMENT User Manual

63
Maintenance and troubleshooting
→ Remove the electronic module by pulling it straight out. There may be a slight resi-
stance due to the seal.
A
→ Remove the used seal "A" from the holder.
→ Place the new seal "A" into the groove of the holder.
Fig. 43 Replacing the seal of the sensor holder
→ Charge the pipe to check that the mounting is tight.
→ Refit the electronic module to the holder as shown in Fig. 17of chap. 8.2.
10.5. Troubleshooting
Red
LED
Current
output
Transistor
output
Icon Message dis-
played in the
Info menu
Possible cause Recommended action
ON 22 mA depending
on
thresholds
ERR
+
"E:Sat. ORP
Stage"
"E:Sat. pH
Stage"
The pH or redox value
is not being correctly
measured due to the
saturation of the input
stage of the measuring
board.
→ Check the correct wiring
of the earth points.
→ Check the equipo-
tential surfaces of the
installation.
ON 22 mA depending
on
thresholds
ERR
+
"Sensor not
found"
The connection to the
measurement module is
interrupted.
→ Switch the power supply
off then on again.
→ If the error persists, return
the device to Bürkert.
ON 22 mA depending
on
thresholds
ERR
+
"S EE Fact
Read"
Factory data is lost.
The process continues
but the accuracy of the
device is modified.
→ Switch the power supply
off then on again.
→ If the error persists, return
the device to Bürkert.
"S EE Fact
Write"
English
Type 8202 ELEMENT
