16
Technical data
6.3.3. Electrical data
Power supply
Version with 3 outputs
Version with 4 outputs
14-36 V DC, filtered and regulated
12-36 V DC, filtered and regulated
Characteristics of the power source (not supplied) of
the UL versions
limited energy source (in accordance to UL 61010-1,
paragraph 9.3)
or Class 2 source (in accordance to standards
1310/1585 and 60950-1)
Current consumption
Version with 3 outputs
Version with 4 outputs
25 mA max. (at 14 V DC)
5 mA max. (at 12 V DC)
Current consumption, with loads on the transistors 1 A max.
Power consumption 40 W max.
Protection against polarity reversal
yes
Protection against voltage spikes
yes
Protection against short circuits
yes, transistor outputs
Transistor output NPN (/sink) or PNP (/source) (depending on software
setting), open collector, 700 mA max., 0.5 A max. per
transistor if both transistor outputs are wired.
NPN output: 0.2-36 V DC
PNP output: supply voltage
Current output
Response time (10 % - 90 %)
Version with 1 current output
Version with 2 current outputs
4-20 mA, sink ("NPN sink") or source ("PNP source")
(depending on software setting)
150 ms (default value)
max. loop impedance: 1100
W at 36 V DC, 610 W at
24 V DC, 180 W at 14 V DC
max. loop impedance: 1100
W at 36 V DC, 610 W at
24 V DC, 100 W at 12 V DC
6.3.4. Data of connectors and cables
Number of fixed connectors Type of connectors
1 male M12 fixed connector 5-pin female M12 connector (not supplied).
For the M12 connector with order code 917116, use a shielded
cable:
diameter: 3 to 6.5 mm
wire cross section: max. 0.75 mm
2
