Operating and functions
TR2: check that transistor output 2 is working correctly by selecting the status of the transistor ("ON" or "OFF")
then "OK".
9.14.3. Checking the outputs behaviour
See chap. 9.9 to access the Test menu.
The
T
icon is displayed in place of the icon as soon as the check for the correct working of an output
has started. During the check the related output does not react according to the measured physical value.
The feature allows for simulating the measurement of the process value to check if the outputs are correctly
configured.
Test
Value:
Sensor
INPUT
PVar: pH
TempC
mV_pH
mV_ORP
TempF
PVAR: choose the process value to be tested.
VALUE: enter a process value selected from the "PVAR" function above to check output behaviour.
9.15. Information menu
9.15.1. Reading the cause of events linked to icons
See chap. 9.9 to access the Info menu.
Info Error
MESSAGE
MESSAGEWarning
MESSAGEMaintenance
MESSAGESmiley
The function allows for reading a short description of the reason why the following icons are displayed by the
transmitter:
- ERROR:
ERR
- WARNING:
- MAINTENANCE:
- SMILEY: or
See also "If you encounter problems" at chap. 10.5
