Burkert 8202 ELEMENT User Manual

17
Technical data
Number of fixed connectors Type of connectors
1 male M12 fixed connector and 1 female
M12 fixed connector
5-pin female M12 connector (not supplied) and 5-pin male M12
connector (not supplied).
For the M12 connector with order code 917116, use a shielded
cable:
• diameter: 3 to 6.5 mm
• wire cross section: max. 0.75 mm
2
6.3.5. pH/Redox probe
The pH or redox probe must satisfies the following specifications:
• combined probe;
• length: 120 mm;
• with PG 13.5 head;
• with an S7/S8 fixed connector;
• without temperature probe.
The specifications of the probe can be found in the manual of the probe used.
English
Type 8202 ELEMENT

Burkert 8202 ELEMENT Specifications

General

Brand	Burkert
Model	8202 ELEMENT
Category	Measuring Instruments
Language	English
