50
Operating and functions
→ choose "enabled";
→ validate by "OK".
In practice, when the device is in Hold mode:
• the
HOLD
!
icon is displayed in place of the icon;
• the current emitted on each 4-20 mA output is fixed at the value of the last measurement of the process value
associated with each output;
• each transistor output is fixed at the status acquired at the moment the Hold function is activated;
• the device is in Hold mode until the HOLD function is deactivated.
To deactivate the HOLD mode:
→ enter the "HOLD" function;
→ choose "disabled";
→ validate by "OK".
9.12.2. Modifying the Calibration menu access code
See chap. 9.9 to access the Calibration menu.
Code 0*** Confirm code 0***Calib System
Enter the new
code
Confirm the new
code
Default access code to the Calibration menu: 0000.
9.12.3. Adjusting the current outputs
WARNING
Risk of injury due to non-conforming adjustment.
• Make sure the Hold mode is disabled (see chap. 9.12.1).
See chap. 9.9 to access the Calibration menu.
Outputs AC1 / AC2
4mA:
20mA:
INPUT
INPUT
Calib
4mA: adjust the current output 1 or current output 2 for 4 mA.
When the "4mA" function is selected, the transmitter generates a current of 4 mA: measure the current emitted
by the 4-20 mA output using a multimeter and enter the value given by the multimeter in the function "AC1.4mA"
or "AC2.4mA".
20mA: adjust the current output 1 or current output 2 for 20 mA.
When the "20mA" function is selected, the transmitter generates a current of 20 mA: measure the current emitted
by the 4-20 mA output using a multimeter and enter the value given by the multimeter in the function "AC1.20mA"
or "AC2.20mA".
English
Type 8202 ELEMENT
