Burkert 8202 ELEMENT User Manual

45
Operating and functions
9.11.6. Displaying the lowest and highest values measured
See chap. 9.9 to access the Parameters menu.
WARNING
Risk of injury due to wrong adjustment.
• Before setting the parameters for the display, choose the type of probe (see chap. 9.11.11) mounted on the
transmitter.
Display
Param
This is
when the
device is be-
ing parame-
tered............
....................
This is
when the
device is be-
ing parame-
tered............
....................
pH
TempC
Min/Max: EnabledStatus:
PVar:
Disabled
mV_pH
mV_ORP
TempF
pH
°C
Unit:
mV
°F
If PVar = "TempC"
If PVar = "TempF"
If PVar = "mV_pH" or "mV_ORP"
If PVar = "pH"
STATUS: choose to display (choice “Enabled”) or not display (choice “Disabled”) the highest and lowest
measured values (of the process value chosen in PVAR hereafter) since the latest reset.
PVAR: choose the process value which highest and lowest measured values are displayed in the Read level.
UNIT: choose the preferred unit in which the lowest and highest measured values are displayed.
9.11.7. Setting the display contrast and brightness
See chap. 9.11.1 to access the Parameters menu.
On a version with one M12 fixed connector, do not increase the default setting of the display brightness
(parameter "Backlight").
Contrast xx%
Backlight xx%
Display
This is
when the
device is be-
ing parame-
tered............
....................
Param
This is
when the
device is be-
ing parame-
tered............
....................
Set each percentage using and .
CONTRAST: Choose the display contrast level (as a %).
BACKLIGHT: Choose the brightness of the display (as a %).
These settings only affect the display module. They are not factored in during a device data UPLOAD (see
chap. 9.11.1).
English
Type 8202 ELEMENT
