30
Installation and commissioning
12-36 V DC
+ -
1
2
3
4
3
2
1
4
Load 1 (solenoid valve for
instance)
Load 2 (solenoid valve for instance)
Power supply
white
blue
brown
grey
white
blue
Fig. 28 PNP wiring of both transistor outputs of a version with 2 fixed connectors (software setting "PNP/source", see
chap. 9.11.8)
12-36 V DC
+ -
+ - + -
1
2
3
4
3
2
1
4
Power supply
1
st
4-20mA input at external device
brown
blue
grey
2
nd
4-20mA input at external
device
black
brown
black
Fig. 29 Wiring of both current outputs in sinking mode, on a version with 2 fixed connectors (software setting "NPN/sink",
see chap. 9.11.8)
12-36 V DC
+ -
+ -+ -
1
2
3
4
3
2
1
4
Power supply
1
st
4-20mA input at exter-
nal device
brown
blue
grey
2
nd
4-20mA input at
external device
black
blue
black
Fig. 30 Wiring of both current outputs in sourcing mode, on a version with 2 fixed connectors (software setting "PNP/
source", see chap. 9.11.8)
English
Type 8202 ELEMENT
