Start-up
Sub-
index
Name Description
Access type
Factory
reset
0x6 Totalizer Valve Cycles
Service Limit
Switching cycles: Activate or deactivate maintenance
threshold
0: Diagnostics deactivated
>0: Diagnostics activated
Warning is output when the number of resettable
switching cycles reaches this threshold
RW x
0x7 Totalizer Time Service
Operating time counter [s] resettable:
Sum of the time for which the device was receiving an
operating voltage.
RO
0x8 Totalizer Time Service
Limit
Operating time counter: Activate or deactivate maintenance
threshold
0: Diagnostics deactivated
>0: Diagnostics activated
Warning is output when the resettable operating time
counter reaches this threshold
RW x
0x9 DiagControlCommand
Reset counters:
The resettable counters can be reset as follows:
Bit0 = 1: Reset switching cycles
Bit1 = 1: Reset travel accumulator
Bit2 = 1: Reset operating time counters
Bit3 = 1: Reset number of opening time timeouts
Bit4 = 1: Reset number of closing time timeouts
Bit5 = 1: Import measured switching
times (0xA and 0xB).
Sourcedependentoncongurationof0x15
Bit6 = 1: Reset number of switching time timeouts
RW
0xA OpeningTimeLimit
Maximum opening time [ms]:
Congurableopeningtimefromwhichawarning(active)
should be generated to indicate potential faults in the
system (e.g. pilot pressure too low, excessive friction in
actuator, etc.).
RW x
0xB ClosingTimeLimit
Maximum closing time [ms]:
Congurableclosingtimefromwhichawarning(active)
should be generated to indicate potential faults in the
system (e.g. pilot pressure too low, excessive friction in
actuator, etc.).
RW x
0xC TimeTolerance
Toleranceforcongurabletimes[%]:
Speciesthetolerancefortheparameters“openingtime
limit” and “closing time limit”, from which point an active
warning is generated.
RW x
