Start-up
Sub-
index
Name Description
Access type
Factory
reset
0xD OpeningErrorCnt
Number of times opening time threshold exceeded
(resettable):
Valueconguredin“openingtimelimit”+“timetolerance”
has been exceeded
RO
0xE ClosingErrorCnt
Number of times closing time threshold exceeded
(resettable):
Valueconguredin“closingtimelimit”+“timetolerance”
has been exceeded
RO
0xF TuneStarts
Number of teach functions performed
RO
0x10 PilotValveCycles
Number of pilot valve switching cycles
RO
0x11 ActiveWarnings
Activewarnings(biteld)
Bit0: Travel accumulator threshold reached
Bit1: Valve switching cycle threshold reached
Bit2: Operating time threshold reached
Bit3: Opening time timeout
Bit4: Closing time timeout
Bit5: Calibration required
Bit6: Tolerance bands overlap
RO
0x12 SwitchingTimeoutCnt
Number of switching timeouts
RO
0x13 ActiveErrors
Activeerrors(biteld)
Bit0: Switching timeout
Bit1: Teach function error
Bit2: Position sensor error
Bit3: IO-Link set-point value error
Bit4: büS/CanOpen set-point value error
RO
0x15 TimeDiagnosticType
Select type of switching times for diagnostics:
0: Use switching time based on CMD set-point
value (0x2C0B sub-index 0x4
and 0x5)
1: Use switching time based on position
(0x2C0B sub-index 0xE
and 0xF)
RW x
0x17 SwitchingTimeoutDe-
tection
Activate or deactivate switching timeout detection:
If activated, switching timeouts are detected whenever the
end position is not reached within a certain time (sub-index
0x18)
0: Deactivated
1: Activated
RW x
0x18 SwitchingTimeout
Select maximum time by which the end position should be
reached
RW x
Table 36: 0x2C0E Diagnostics
