4. Select the correct C-Code.
! Use the
""
""
"
(S2) and
!!
!!
!
(S1) keys to scroll through the available C-Codes in the
adapter, then press ENTER when the correct C-Code is displayed.
! Press ENTER again to confirm the selection. The selected C-Code now
becomes active, indicated by the “
!!
!!
!”.
If a Smart Cable Adapter is first used, create a custom C-Code:
! Press CCode.
! Use the
""
""
" (S2) and
!!
!!
! (S1) keys to select or the keypad to enter the settings.
Advance or go back using the
$$
$$
$ (S4) and
##
##
# (S3) keys.
! Press ENTER and select Yes. Now you can proceed to step
7 to start service.
Refer to
Battery Configuration/C-Codes
to add or edit C-Codes.
Warning: Always use the correct C-Code, especially the correct chemistry.
Failure to do so may cause damage to the battery, fire or explosion.
5. Select program. (Refer to
Battery Service Programs
for the various programs
and their uses.)
! Press the PROG key.
! Use the
""
""
" (S2) and
!!
!!
! (S1) keys to scroll through the available programs, then
press ENTER when the desired program is displayed.
! Press ENTER to confirm the selection. To cancel, press Esc.
6. Verify the settings again after pressing ENTER.
18 C7000 & 7000ER Battery Analyzer V3.5
