Servicing Batteries with Bar Code
This applies when the analyzer is equipped with the OP-72 option board which supports
a bar code reader.
1. Print Bar Code Labels: one with Battery ID, one with C-Code. (Refer to
Print
Utilities
for detailed procedures.)
2. Place the labels onto the battery.
3. With the Battery Adapter inserted, select the station by pressing the station key.
4. Scan the Battery ID.
5. Scan the C-Code.
6. When the READY (green) light flashes, insert the battery and press ENTER to
start service.
Note that the active C-Code displayed is
C11
, a read-only position in the
adapter reserved for bar code entries.
20 C7000 & 7000ER Battery Analyzer V3.5
