Cadex C7000 - Serial and Parallel Port Device Settings

DB-9 to DB-9
DB-9 DB-9
RD 2 -- 3 TD
TD 3 -- 2 RD
CTS 8 -- 7 RTS
RTS 7 -- 8 CTS
SG 5 -- 5 SG
Note: If connecting to a serial printer, it may also be
necessary to jumper pins 6 (DSR), 1 (DCD), and 4 (DTR)
together on the printer’s DB-9 connector. Other jumpers
may be also required. Check your printer manual for
specific information.
Serial and Parallel Port Device Settings
The serial port is a DB9 connector which is standard on all models and is located at
the back of the analyzer.
The parallel port is a DB25 connector available only to analyzers with the OP-70 or
OP-72 option boards.
System Setup 9
47
Option Description
Disabled No output is provided to the serial port.
Printer Print reports and labels on a serial printer.
LabelMaker (Default Setting) Print Bar-Code Labels and Battery Labels on
a DYMO LabelWriter SE300 Printer.
Computer Transfer service data to the computer.
BatteryShop Connect to BatteryShop.
Option Description
Disabled No output is provided to the parallel port.
Printer (Default Setting) Print reports and labels on a parallel printer.
LabelMaker Print Bar-Code Labels and Battery Labels on a DYMO
LabelWriter SE300 Printer.
