Setting Up System Information
1. Select the feature on the menu.
2. Enter the required information or select the settings.
! Use the
""
""
" and
!!
!!
! keys to scroll through and select the option, numbers or
characters in both upper and lower cases.
! Use the
$$
$$
$ and
##
##
# keys to move the insertion point.
3. Select Yes to accept changes.
Calibration Procedures
Calibrating Voltage
You need a calibration kit (P/N 92-770-0210). This kit can be purchased from Cadex or
through your Cadex Representative. The C7000 calibration kit consists of 4 calibration
adapters (P/N 07-130-0000) and an instruction sheet (P/N 89-204-1017).
Servicing the Voltage Calibration Adapters: Return the Voltage Calibration Adapters
to the factory every 3 years for authorized calibration. Call Cadex for a Return
Authorization number.
44 C7000 & 7000ER Battery Analyzer V3.5
CALIBRATION
Voltage Calibration
Station Calibration
ENTER
