Specifications
Hardware
14
73
C7000-1
Standard
C7000-2
Standard
C7000-9
Standard
C7000-ER
Extended Range
Part Number
07-771-0000 07-772-0000 07-779-0000 07-778-0000
Line Voltage
115VAC +
10% 100VAC +10% 220-240VAC +5% 90-250VAC
Frequency
60Hz 50-60Hz 50-60Hz 47-63Hz
Main (Input) Load
max 180W max 180W max 180W 225W (Power
Factor Corrected)
Output Load
Total* max 80W max 80W max 80W max 160W
Current/Station max 2A max 2A max 2A max 2A
Operating Temp. 0
o
C to 40
o
C (32
o
F to 104
o
F)
Dimensions
Width 280mm (11.0") 280mm (11.0") 280mm (11.0") 280mm (11.0")
Depth 374mm (14.7") 374mm (14.7") 374mm (14.7") 412mm (16.7")
Height 88mm
(3.6") 88mm
(3.6") 88mm
(3.6") 95mm
(3.75")
Weight
6.3kg (13.9lb); with option board: 6.4kg (14.1lb) 5.7kg (12.6lb)
Accuracy
Voltage +
1% at max rated voltage
Current +
2.5% at 1A
Throughput
4 batteries every 4 - 8 hours (up to 160 batteries per month) based on 2 batches
per day.
Connectors
3-pin AC plug IEC320 Power Cord (only available on C7000-1)
Serial DB-9 RS-232 (standard on all models)
Parallel DB-25 (OP70 and OP-72 only)
DIN Jack (5-pin) for Bar Code Wand (OP-72 only)
Interface
LCD 80 Character with multiple display formats (Global, Detailed, Menu)
LED 3 Status lights (RUN, READY, FAIL) for each station
Keypad Numeric pad with 8 function keys, 4 station selection/cursor keys
Warranty
Limited (2) years parts and labor
Approvals
Tested and approved by ITS to comply with CSA/UL/CE standards
Options
Battery Backup RAM (OP-70 and OP-72)
Bar Code Reader (OP-72)
Windows-based BatteryShop
TM
* Continuous, intelligent overload protection.
