Extended C-Code
28 C7000 & 7000ER Battery Analyzer V3.5
Parameter Description
Charge Rate A 1000mAh capacity with a charge current of 500mA
will have a Charge C-rate of 0.50C. A lower Charge
C-rate reduces the charge current and increases
service time. The maximum charge current is
2000mA (2A).
Discharge Rate A 1000mAh capacity with a discharge current of
500mA will have a Discharge C-rate of 0.50C. A
lower Discharge C-rate reduces the discharge
current and increases service time.The maximum
discharge current is 2000mA (2A).
Trickle Charge Rate
(NiCd and NiMH only)
Amount of trickle applied to maintain the charge on a
battery after service. From 1% to 10% in increments
of 1%.
Recondition
Discharge Rate
(NiCd and NiMH only)
A slow and gradual discharge after the battery
reaches the End of Discharge voltage. During this
process, the crystalline build-up (memory) on the cell
plates dissolves and the battery often restores itself.
From 2% to 20% in increments of 2%.
Capacity Offset Adjusts the capacity readings when discharging a
battery at a higher or lower C-rate than specified by
the manufacturer.
Mainly used for SLA batteries. From -50% to +49%
in increments of 1%.
Temperature Sensing The temperature range in which a station will service
the battery. Effective only for batteries or adapters
equipped with temperature sensor.
Negative Slope
(NiCd and NiMH only)
A measure of the voltage drop when the battery
reaches full-charge. The charge cycle is terminated
when the voltage drop reaches the set value. From
16 to 64mV/Cell.
