Phase Done
Example
NiCd or NiMH batteries that do not meet the Target Capacity should always be
reconditioned. If the battery does not meet the Target Capacity after reconditioning, the
program will fail the battery. This is a shortened version of the Auto program because
this program does not determine the initial capacity of the battery when it came from the
field.
Option Description
Ready - No Charge Complete the program. The READY light will be
on and no trickle charge is applied.
Ready - Trickle Charge Trickle charge the battery according to the
Trickle Charge rate in the Extended C-Code.
Includes the Standby maintenance cycle which
periodically performs discharge/charge every 30
days (180 days for SLA).
Trickle Charge Trickle charge the battery according to the
Trickle Charge Rate in the Extended C-Code.
Phase Action
Phase 1 Discharge for 10 minutes to avoid charging a fully charged battery.
Then fully charge the battery.
Phase 2 Discharge to find the battery capacity. If the capacity meets the
Target Capacity, complete the program (Phase Done). If the Target
Capacity is not met, apply the recondition cycle (Phase 3).
Phase 3 Recondition and charge the battery.
Phase 4 Discharge to find capacity after the recondition cycle. If the
capacity meets the Target Capacity, charge the battery (Phase 5).
If the Target Capacity is not met, fail the battery.
Phase 5 Fully charge the battery.
Phase Done Complete the program with a trickle charge to maintain capacity.
38 C7000 & 7000ER Battery Analyzer V3.5
