System Setup 9
45
1. Make sure that no Battery Adapter is inserted.
2. Select Voltage Calibration on the menu.
3. Firmly insert the 4 Voltage Calibration Adapters into each station.
4. Wait for the prompt, then remove the calibration adapters.
5. Press Menu to return to the Global Display.
6. Press Fn-7. The “#” sign should appear in the upper right corner of the
startup screen, indicating successful completion of voltage calibration.
Calibrating Station
Failing to calibrate Battery Adapters could cause inaccurate capacity readings,
especially on low voltage batteries or single cells.
Recalibrate adapters when they
are moved from one station to another.
1. Make sure that there is no battery inserted into the adapter.
2. Select Station Calibration on the menu. You can also press Fn-8.
3. For each station, select the station and short the battery leads
on the
adapter
together using a short length of heavy gauge wire (AWG 10).
Warning: Never short the contacts on the battery.
4. Once the display indicates that a good connection has been established,
press ENTER to start calibrating.
5. Wait for a few seconds and remove the wire when prompted.
