Output Devices
Serial Port Settings
Before connecting any device to the serial port, match the serial port settings with those
of the device being connected.
Consult the device’s manual for the proper settings.
Serial Cable Pin Configurations
Option Available Settings Default
Baud Rate 1200, 2400, 4800, 9600 9600
Handshake NONE, CTS/RTS, XON/XOFF CTS/RTS
Data Bits 7, 8 8
Stop Bits 1, 2
1
Parity NONE, ODD, EVEN NONE
DB-9 to DB-25
DB-9 DB-25
RD 2 -- 2 TD
TD 3 -- 3 RD
CTS 8 -- 4 RTS
RTS 7 -- 5 CTS
SG 5 -- 7 SG
Note: If connecting to a serial printer, it may also be
necessary to jumper pins 6 (DSR), 8 (DCD), and 20
(DTR) together on the printer’s DB-25 connector. Other
jumpers may also be required. Check your printer
manual for specific information.
OUTPUT
DEVICES
Serial Port Device
Serial Port Settings
Parallel Port Device
ENTER
BatteryShop
46 C7000 & 7000ER Battery Analyzer V3.5
