Custom Programs
Warning: Creating a Custom Program requires a good understanding of
rechargeable batteries and the analyzer.
Applying routines that conflict with
the battery manufacturer’s specifications or recommendations can damage a
battery.
If you regularly modify Custom Programs, we strongly recommend BatteryShop.
The graphical user interface of BatteryShop allows easy programming. Refer to
BatteryShop Help for detailed instructions.
Custom Programs run virtually any sequence of service cycles. They are stored in
the analyzer and can be assigned to any C-Codes in the adapters.
A Custom Program consists of 6 phases: Phase 1-5 and Phase Done.
• Each of the first 5 phases consists of 2 cycles (Cycle 1 and Cycle 2), Test
and the True and False statements.
• Phase Done consists of one cycle.
The analyzer will go through the first phase, then follow the paths taken by the
decision making True and False statements in each phase. The following lists
describe the values allowed for the cycles, the True and False statements and the
Done phase.
Cycle 1 Cycle 2 Test True / False
Next Phase
Previous Phase
33
