Cycle 1 and Cycle 2
*If the default time period of 000:00:00 is used, the analyzer will service the battery
according to End of Charge, End of Discharge or End of Recondition set in the
Extended C-Code.
34 C7000 & 7000ER Battery Analyzer V3.
Option Description
Skip Cycle Skip the cycle and go to the next cycle or the
Test
statement.
Discharge Time
(Discharge for 000:00:00
@100%)
Discharge the battery for the specified time
period (in hhh:mm:ss format)* at the specified
setting.
A setting of 50% will give a discharge current
that is 50% of the Discharge rate. The
Discharge rate is set in the Extended C-Code.
Charge Time
(Charge for 000:00:00)
Charge the battery for the specified time period
(in hhh:mm:ss format)*. The Charge rate is set
in the Extended C-Code.
Recondition Time
(Recondition for 000:00:00)
Recondition (Deep discharge) the battery for
the specified time period (in hhh:mm:ss
format)*.
The Reconditioning Discharge rate is set in the
Extended C-Code. This cycle will be skipped
for SLA or Li-Ion as these chemistries cannot
be reconditioned. This cycle can only be
applied after a discharge cycle.
Trickle Charge Time
(Trickle Chg for 000:00:00)
Trickle charge the battery for the specified time
period (in hhh:mm:ss format).
The Trickle Charge rate is set in the Extended
C-Code and only applies to NiCd/NiMH.
Rest Time
(Rest for 000:00:00)
Apply no current for the specified time period
(in hhh:mm:ss format).
The time must be specified or the cycle will be
skipped.
OhmTest Perform the OhmTest on the battery.
In this case, the resistance threshold is not
definable.
