Messages and Warnings 12
55
Detail Global Possible Reason(s) / Solution(s)
C
Calibrate CALIBRATE Calibration in process. Process will complete in 10
seconds.
Calibration fault FAIL 170 Current cannot pass through shorted terminal during
calibration. Repeat calibration procedures. An AWG 10
(2.5mm) wire is recommended to short contacts/leads.
Cap. improved to
target
READY Target Capacity is achieved or exceeded after an initial
warning (code 115, Target capacity not met).
C-Code locked C-CODE
LOCKED
C-Code is locked and cannot be edited. Use an unlocked
C-Code or delete and re-enter the C-Code.
Cell mismatch WARNING For NiCd batteries only. The cells reach full charge at
different times so the negative slope is not well-defined.
The program proceeds to the next cycle as normal. Wait
until processing is complete since the
Auto
and
Prime
programs will attempt to correct this warning. If corrected,
code 192 (Cell mismatch corrected) will appear.
The negative slope in Extended C-Code may have to be
increased to 32mV/Cell or more.
Battery may be old and operating time is reduced. Either
monitor battery use or discard the battery.
If the battery is new, use the
Prime
program.
Cell mismatch
corrected
READY Cell mismatch (code 112) is corrected through several
Charge/Discharge cycles. Use the battery as normal.
Charge complete hot WARNING Battery is fully charged but the temperature is at or above
the maximum set value in the C-Code. See code 154,
Chrg complete temp rise, for details.
For non OEM battery, turn off temperature sensing in the
C-Code.
Charge current low FAIL 164 Current driver cannot provide the requested charge current.
See code 160, Bad fuses or driver.
Charge current
complete
END
CYCLE
Charge cycle completed. Program is going into the next
step.
