Cadex C7400 User Manual

Appendix C
Specifications
Hardware
Battery Analyzers
C7200-C C7400-C C7400ER-C
Part Numbers
07-720-0100 07-740-0100 07-740-1100
Independent stations 2 4 4
Battery voltage 1.2-16V 1.2-16V Li-ion and SLA 1.2-36V
NiCd and NiMH: 1.2 – 28.8V
Charge/discharge
current
100mA-4A 100mA-4A 100mA-6A*
Accuracy +/- 1% at max rated voltage, +/- 2% at 4000mA
Services batteries up to 24Ah. If set above 4A*, the current automatically scales
down.
Maximum charge power
40W per station;
40W total
55W per station;
80W total
75W per station; 170W total
Maximum discharge
power
35W per station;
70W total
35W per station;
140W total
75W per station; 200W total
Power management On high load demands, the current scales down; large batteries may go on waiting
queue
Line voltages 100-240VAC, 50-
60Hz; 1.5A max
100-240VAC, 50-
60Hz, 1.75A max
100-120/200-240VAC, 50-60Hz;
4A max
Chemistries Lithium-ion, Lithium-phosphate, nickel-metal-hydride, nickel-cadmium, lead-acid
Charge method Automatic full charge detection, safe termination under all conditions. Temperature
controlled.
Lithium-phosphate, Lithium-ion and lead-acid: constant voltage with current limit.
Nickel-based: constant current with Reverse Load adjustable from 5-12%.
Customized charge methods possible.
Discharge method Constant discharge current to end-of-discharge voltage threshold
Battery Adapters Custom and universal SnapLock™ adapters. Each adapter holds up to 10 C-codes
to service different battery types. Re-programmable with menu function.
Cadex Electronics Inc. C7000-C Series Battery Analyzers .
152
