Learn
C7000 C-series firmware will not display a matrix made with
C7000 series firmware. Therefore, run the Learn program again
to create a new matrix.
Ensure that battery contacts and adapter contacts are clean.
Dirty contacts will affect QuickTest readings.
Function: Learn creates and stores a matrix in a C-code for use by QuickTest.
Sequence: The Learn program applies several charges, discharges and OhmTest
to obtain a battery profile called a matrix. This matrix is automatically stored in the
C-code.
Results: Detailed display shows three decreasing capacity percentages as well as
average cell voltage; analyzer charge or discharge current (in mA); OhmTest
results; battery temperature and duration of service. The C-code display screen
shows a T in the upper right-hand corner to indicate that a C-code, saved as a
matrix, has been stored for using with the QuickTest program.
Duration: 4 – 8 hours depending on battery capacity and default C-codes.
Learn Limitations
Learn is available only on 16K Battery Adapters. ‘16K’ is marked on the rear label
of the adapter.
Only custom adapters should be used. Universal adapters such as the Universal
Alligator Clips Adapter (07-110-0115), the RigidArm (07-110-0190) and the
FlexArm (07-110-0180) are NOT recommended. These adapters create inaccurate
results due to resistance errors.
Learn and QuickTest cannot be used with the following batteries:
o SLA batteries greater than 2Ah (2000mAh).
o Some 1-cell (1.20V) and 2-cell (2.40V) NiCd and NiMH batteries.
Cadex Electronics Inc. C7000-C Series Battery Analyzers .
40
