Cadex continuously designs and manufactures adapters for new battery models. A
list of current Battery Adapter models is available in the adapter catalog available in
print or on the Cadex website. Contact Cadex for a current adapter catalog or
download a copy from our web site at www.cadex.com. Cadex also designs custom
adapters for a wide variety of applications. A Battery Adapter Design Form can be
downloaded from the Cadex website and used to order a custom adapter.
To insert an adapter
1. Place the empty Battery Adapter into the Battery Adapter station,
putting the front end in place first.
2. Press down on the back panel (with the label) until the adapter snaps
in place.
The LCD display for the station changes from NO ADAPT to EMPTY, indicating that the
Battery Adapter has been inserted but does not contain a battery. The second line
of the display indicates the program that was selected in the C-code. If the adapter
displays NULL CODE, the C-code has not been programmed, (see Create or Edit a
C-code, page 62).
OBSERVE POLARITY! Do not connect the Universal adapter to
the battery with the leads reversed or insert the battery into the
adapter in reverse.
To remove an adapter
1. Remove the battery from the adapter first.
2. Press the latch bar behind the label on the adapter and lift the adapter
upwards.
19
