5. Remove the Harness Guide.

6. Remove the Main Controller PCB.

NOTE:

The completed assembly of the Main Controller PCB is shown below.

CAUTION:

“After Replacing the Main Controller PCB” on page 178

5. Parts Replacement and Cleaning

143
