● Restoration from a USB Flash Drive
You can import (restore) a setting information file exported (backed up) to a USB flash drive to the host machine.
1. Connect the USB flash drive to the Memory Port.
2. Execute the following service mode to import the setting values saved in the USB flash drive to the host machine.
• SERVICE MODE > FUNCTION GR. > ECONF > IMPORT >Yes
FUNCTION GR.
ECONF
Import/Export Set.
SMD-EXPT
USB-H
ECONF
EXPORT
IMPORT
SERVICE MODE
COUNTER GR.
ADJUST GR.
OPTION GR.
FUNCTION GR.
Execute?
No
Yes
3. Remove the USB flash drive when the previous screen is displayed again after the export processing is complete.
ECONF
EXPORT
IMPORT
Executing... Done.
4. Access service mode and confirm that the settings are reflected.
5. Remove the USB flash drive.
Import Export Set.
IMPORT
EXPORT
Ready to print files
from USB memory.
<Remove USB Memory>
Select File(s)
Sort Files
Remove USB memory?
No
Yes
Application
■ Backup/restoration using the Expansion ROM for servicing and the Sublog
Board
Use the Expansion ROM for servicing and the Sublog Board to migrate the setting information in a failed Main Controller PCB to
an unused Main Controller.
Target data for backup
Target data for backup is as follows: (For details, see [Appendix] > [Backup Data List] in this manual.)
• User mode setting values
• Service mode setting values
