Canon imagePROGRAF iPF815 User Manual

*6: Not displayed if NetWare is Off.
*7: Not displayed if Auto Detect is On.
*8: Follows the setting in Date Format.
*9: Displayed if the Media Take-up Unit is attached.
*10: Available after you have used Advanced Adj. in Auto Head Adj. once.
*11: Available if: (a) Take-up Reel is Enable, (b) roll paper is loaded, and (c) you have not executed Auto Feed
for the loaded roll.
*12: Not displayed if IP Mode is Automatic.
*13: Follows the setting in Length Unit.
*14: Leading edge is not available as a setting option in the Paper Detailed Settings dialog box of the printer driv-
er.
*15: Viewing and configuration is possible for administrators, and only viewing for other users.
*16: Viewing and configuration is possible for administrators only.
*17: Default setting for the time to enter the power save mode/Sleep mode is recommended.
Caution
• Only the following menus are displayed during printing.
Choose this menu to display Head Cleaning, Fine Band Adj., and Information.
Choose this menu to display Job Management.
Submenus
Each time you press the Information button on the Control Panel, printer information is displayed in the following order.
• The remaining Maintenance Cartridge capacity and ink levels
• Information on the loaded paper
Printer Parts
> Control Panel >
iPF815 Menu Structure
9
721

Canon imagePROGRAF iPF815 Specifications

General

Color	Yes
Printing colors	Black, Cyan, Magenta, Pigment matte black, Yellow
Maximum resolution	2400 x 1200 DPI
Number of print cartridges	5
Package weight	301200 g
Bundled software	Printer Driver Extra Kit for Windows/Mac (Free Layout, Color imageRUNNER Enlargement Copy, Advanced Preview), Print Plug-in for Microsoft Word/Excel/PowerPoint for Windows, Digital Photo Front-Access for Windows, PosterArtist Lite for Windows
Media thickness	0.07 - 0.8 mm
Roll top margin	3 mm
Maximum print size	-
Maximum roll length	18 m
Maximum roll diameter	150 mm
ISO A-series sizes (A0...A9)	A0, A1
ISO B-series sizes (B0...B9)	B0, B2
Electromagnetic compatibility	RoHS Directive, WEEE, Executive Order (USA)
Power requirements	AC 100 - 240V, 50/60Hz
Power consumption (off)	1 W
Power consumption (standby)	6 W
Power consumption (typical)	190 W
Certification	UL (USA), C-UL (Canada), S mark (Argentina), CE mark (EN60950, EN55022 classB, EN61000-3-2, EN-61000-3-3, EN55024) (EU), CB certification (Others), FCC Class B (USA), IC Class B (Canada)
Storage media	HDD
Internal storage capacity	160 GB
Sound power level (standby)	35 dB
Sound pressure level (printing)	52 dB
USB connector	USB Type-A
USB 2.0 ports quantity	1
Ethernet LAN data rates	10/100Base-T/TX Mbit/s
Sustainability certificates	ENERGY STAR
Operating temperature (T-T)	15 - 30 °C
Operating relative humidity (H-H)	10 - 80 %
Compatible operating systems	Windows XP (32/64 bit), Server 2003 (32/64 bit), Server 2008 (32/64 bit), Windows Vista (32/64 bit), Windows 7 (32/64 bit); Macintosh OS X 10.3.9 - 10.6 (32 bit), OS X 10.5 - 10.6 (64 bit)

Weight and Dimensions

Dimensions (WxDxH)	1892 x 975.4 x 1143 mm
