7–13 62-11640
00021 TECHNICIAN RESET REQUIRED
• ACTIVATION: The High Engine Temp Shutdown Configuration and/or Engine Oil Pressure Shutdown
Configuration is/are set to YES, and either Alarm 00011 - Low Engine Oil Pressure, or Alarm 00012 -
High Coolant Temperature has become active and shut the unit down three times within the past 2 hours.
• UNIT CONTROL: Engine Operation: Engine and unit shutdown and alarm.
Electric Operation: This alarm will not activate in Electric Operation
• RESET CONDITION: Clear the alarm from inactive alarm list. This alarm and the alarm(s) that caused it
can not be reset by turning switch OFF and then ON again.
NOTE: Follow the steps below until a problem is found. Once a repair or correction has been made, the active
alarm should clear itself (refer to reset condition above). Operate the unit through the appropriate modes to see
if any active alarm occurs. Continue with the steps below as necessary.
CORRECTIVE ACTIONS:
1. Determine Which Alarm Activated This Alarm.
a. Check active alarm list for Alarm 00011 CHECK ENGINE OIL PRESSURE or 00012 HIGH COOL-
ANT TEMPERATURE. One of these alarms will be present.
b. Follow the troubleshooting steps for the alarm(s) found, and correct the alarm condition. All alarm
conditions must be corrected.
2. Reset Alarm
Clear all inactive alarms. Refer to Section 5.2.2. All alarms must be cleared to start unit.
