Table 8–3 Sensor Resistance
Sensors AAT, RAT, SAT, ENCT, DTT, CST, EVTO, REMSN 1, 2, & 3
°F °C Ohms °F °C Ohms °F °C Ohms °F °C Ohms
-40 -40 336,500 18 -7.8 49,060 76 24.4 10,250 134 56.7 2,809
-38 -38.9 312,600 20 -6.7 46,230 78 25.6 9,760 136 57.8 2,697
-36 -37.8 290,600 22 -5.6 43,580 80 26.7 9,299 138 58.9 2,590
-34 -36.7 270,300 24 -4.4 41,100 82 27.8 8,862 140 60.0 2,488
-32 -35.6 251,500 26 -3.3 38,780 84 28.9 8,449 142 61.1 2,390
-30 -34.4 234,200 28 -2.2 36,600 86 30.0 8,057 144 62.2 2,297
-28 -33.3 218,200 30 -1.1 34,560 88 31.1 7,686 146 63.3 2,208
-26 -32.2 203,400 32 0 32,650 90 32.2 7,334 148 64.4 2,124
-24 -31.1 189,700 34 1.1 30,850 92 33.3 7,000 150 65.6 2,042
-22 -30 177,000 36 2.2 29,170 94 34.4 6,684 155 68.3 1,855
-20 -28.9 165,200 38 3.3 27,590 96 35.6 6,384 160 71.1 1,687
-18 -27.8 154,300 40 4.4 26,100 98 36.7 6,099 165 73.9 1,537
-16 -26.7 144,200 42 5.5 24,700 100 37.8 5,828 170 76.7 1,402
-14 -25.6 134,800 44 6.6 23,390 102 38.9 5,571 175 79.4 1,281
-12 -24.4 126,100 46 7.7 22,160 104 40.0 5,327 180 82.2 1,171
-10 -23.3 118,100 48 8.9 20,990 106 41.1 5,095 185 85.0 1,072
-8 -22.2 110,500 50 10 19,900 108 42.2 4,874 190 87.8 983
-6 -21.1 103,600 52 11.1 18,870 110 43.3 4,665 195 90.6 902
-4 -20 97,070 54 12.2 17,900 112 44.4 4,465 200 93.3 829
-2 -18.9 91,030 56 13.3 16,980 114 45.5 4,275 205 96.1 762
0 -17.8 85,400 58 14.4 16,120 116 46.7 4,095 210 98.9 702
2 -16.7 80,160 60 15.5 15,310 118 47.8 3,923 215 101.7 647
4 -15.6 75,270 62 16.6 14,540 120 48.9 3,759 220 104.4 598
6 -14.4 70,720 64 17.7 13,820 122 50.0 3,603 225 107.2 553
8 -13.3 66,460 66 18.9 13,130 124 51.1 3,454 230 110.0 511
10 -12.2 62,500 68 20.0 12,490 126 52.2 3,313 235 112.8 473
12 -11.1 58,790 70 21.1 11,880 128 53.3 3,177 240 115.6 438
14 -10.0 55,330 72 22.2 11,310 130 54.4 3,049 245 118.3 406
16 -8.9 52,090 74 23.3 10,760 132 55.6 2,926 250 121.1 378
To Next Page
