SETPOINT(S) & RANGE LOCK
DECIMAL DISPLAYED DISPLAYED = setpoint will be shown with a decimal
and temperatures may be selected to a tenth of a de-
gree.
NOT DISPLAYED NOT DISPLAYED = setpoint will not be shown with a
decimal. All other temperatures will still be displayed
with a decimal.
MIN SETPOINT -22°F TO 90°F (-30°C
to 32°C) in 0.1°F or °C
increments
Indicates to the main microprocessor the desired
minimum allowable set point.
MAX SETPOINT -22°F TO 90°F (-30°C
to 32°C) in 0.1°F or °C
increments
Indicates to the main microprocessor the desired
maximum allowable setpoint.
RANGE 1 LOCK
OR
RANGE 2 LOCK
OFF
START-STOP
CONTINUOUS
OFF = If both Range Locks are OFF, the unit will op-
erate normally.
If either Range 1 or Range 2 is not OFF, the unit will
operate as selected whenever the setpoint is within
that range
START-STOP = The unit will always operate in Start-
Stop whenever the setpoint is between the minimum
& maximum temperatures for that range (refer to the
following sub-configurations).
CONTINUOUS = The unit will always operate in
Continuous Run whenever the setpoint is between
the minimum & maximum temperatures for that
range (refer to the following sub-configurations).
RANGE 1 (or 2) MINIMUM
TEMPERATURE
-22°F TO 90°F (-30°C
to 32°C) in 0.1°F or °C
increments
Select the lowest temperature desired for this Range.
RANGE 1 (or 2) MAXIMUM
TEMPERATURE
-22°F TO 90°F (-30°C
to 32°C) in 0.1°F or °C
increments
Select the highest temperature desired for this range.
START-STOP SETTINGS
CURRENT FOR S/S SHUTOFF 7.0A
1A TO 10A (in 0.5A in-
crements)
In Start-Stop Operation the charging current must
drop below this value before the unit is allowed to
shut down.
VOLTAGE FOR S/S RESTART 12.2V
12.0 TO 12.8V
The engine will restart from a Start-Stop Off cycle or
a Sleep Mode Off cycle when the battery drops to this
value.
A lower selection may result in a longer off cycle
(based on battery voltage) and possibly overall short-
er battery life. A higher selection may result in a
shorter off cycle (based on battery voltage) and pos-
sibly overall longer battery life.
ENGINE TEMP FOR S/S RE-
START
10°F (-12.23°C)
10°F to 32°F
(-12.23°C to 0°C)
The engine will restart from a Start-Stop Off cycle or
a Sleep Mode Off cycle when the engine coolant
temperature drops to this value.
Table 5–1 Configuration Settings
(Refer to Section 5.2.3 for instructions on entering Configuration settings)
