2–19 62-11640
Figure 2.10 Refrigeration Circuit Economized Mode
CSMV
COMPRESSOR
SUCTION
SERVICE VALVE
EVXV
COMPRESSOR
ECONOMIZER
CONNECTION
LIQUID LINE
SERVICE VALVE
COMPRESSOR
DISCHARGE
SERVICE VALVE
CONDENSER
SUBCOOLER
FILTER DRIER
LIV N/C
RECEIVER
FUSIBLE
PLUG
EVAPORATOR
EVOT EVOP
ECONOMIZER
ECXV
ECOP
ECOT
CDP
CDT
CST
CSP
MM
MM
DISTRIBUTOR
DISCHARGE FLOW
LIQUID FLOW
SUCTION FLOW
ECONOMIZER SUCTION FLOW
ECONOMIZER LIQUID FLOW
LIQUID
INJECTION LINE
