2.7 ENGINE DATA
2.8 COMPRESSOR DATA
Unit Specification
Engine Model V2203L−DI−EF01e (26−00135)
Rated Power 24.7 hp (18.5 KW) @1800 rpm
Displacement 135 in3 (2.2 liters)
No. Cylinders 4
NOTE
Refer to Table 2–1 for engine speed settings
Weight 434 lbs (197 kg)
Coolant Capacity 2.9 U.S. gallons (11 liters) - 50/50 mix - never to exceed 60/40.
Use Texaco Havoline extended life coolant or any other extended
life coolant which is Dexcool approved and has 5/150 (5 years /
150,000 miles) on the label.
Thermostat Starts to open 177 to 182°F (81 to 83°C). Fully open at 203°F (95°C).
Fuel System
Fuel Winter: Diesel No. 1 Summer: Diesel No. 2 (Max 5% Bio-Diesel also allowed)
Fuel Heater Temperature
Switch
Spin on filter = Close on a temperature fall @ 45°F (7.2°C) open on a temperature
rise @ 75°F (24°C). Suction side filter = 53 +/− 7°F (11.7 +/−3.8°C)
Firing Order 1-3-4-2
Engine Preheater (EPH) 42 amps at 12 VDC, resistance approximately 0.3 Ohms
Lubrication System
Engine Oil Pressure 40 to 62 psig (2.8 To 4.2 Bar) - Engine in high speed
Engine Oil Pressure Safety
Switch (ENOPS)
Closes, on pressure rise, at 18 psig (1.22 Bar) Opens, on pressure fall, at 12 psig
(0.82 Bar)
Oil Capacity with Filter 15 quarts (14.2 liters)
Engine Oil Viscosity: API CG or
better OR Mobil Delvac 1
If Outdoor Temp below 32°F (0°C), use 10W30 or Mobil Delvac 1 (5W 40)
If Outdoor Temp above 32°F (0°C), use 10W30 or Mobil Delvac 1 (5W 40) or 15W 40.
Engine Oil Change Intervals Refer to Section 8.2 for information on service intervals.
Battery 12 volt nominal - 90 amp hour capacity Cold cranking amps = 425 DIN, 500 IEC,
725 BCI
NOTICE
Unit Specification
Compressor Part Number 18-10151-00
Type Hermetic Scroll
Displacement 8.81 Cubic Inches Per Revolution
Weight 88.5 lbs (40.14 kg) Dry
Oil Change 60 ounces (1.77 liters) (Service Replacement)
Approved Compressor Oil Uniqema Emkarate RL-32-3MAF Carrier Part Number 46-00025-04
