10–5 62-11640
ENCU
1
22
23
44
Component Terminal
ENCTïB 1
ENSSNï2 2
ENCTïA 6
RPSï3 7
ENOPSïA 15
ENOPSïB 18
ENCU GND A 19
ENSSNï1 20
SM 21
SPï18 22
SPï13 23
SPï14 24
RPSï2 27
RPSï1 29
FSAï1 36
FSAï2 41
ENSSNï3 43
SPï29 44
Unused Terminals: 3ï5, 8ï14, 16, 17, 25, 26,
30ï35, 37ï40, 42
HVB7
AE
FK
From Terminal
SPï15 A
SPï16 B
1MMï2 C
1MMï4 D
PCMï10 E
PMCï15 F
SPï14 G
SPï13 H
SPï10 J
SPï23 K
Unused Terminals: None
