Carrier TRANSICOLD Vector 8500 User Manual

62-11640 10–8
10.2 HARNESS CONNECTORS, CONTROL BOX
10.3 WIRING SCHEMATIC
The wiring schematics are provided on the following pages.
1CCB
1
12
24
35
Component Terminal
HVB9ï3 1
SPï60 2
SPï61 3
SPï52 4
HVB6ï3 5
2CCB6 6
SPï59 10
SPï57 12
HVB9ï2 13
SPï55 14
SPï51 15
HVB6ï4 17
SPï64 19
CDCON2ïA1 20
HVB9ï1 24
SPï50 26
2CCB29 29
SPï56 31
CDCON1ïA1 33
SPï58 34
SPï65 35
Unused terminals: 7, 8, 9, 11, 16, 18, 21, 22, 23,
25, 27, 28, 30, 32
2CCB
1
12
24
35
Component Terminal
SPï62 1
CCONïA1 2
SPï52 4
HVB6ï8 5
HVB5ï6 9
HVB5ï3 10
SPï63 12
HTCON2ïA1 13
SPï55 14
SPï51 15
HVB5ï7 16
HVB6ï7 17
2CCBï30 18
HVB5ï5 20
HTCON1ïA1 24
SPï50 26
HVB5ï8 28
1CCB29 29
2CCBï18 30
HVB5ï4 33
1EVCONïA1 34
SPï71A 35
Unused terminals: 7, 8, 9, 11, 16, 18, 21, 22, 23,
25, 27, 28, 32
