8
(iii) When the delimiter “C/R+L/F” is selected (Refer to 14.3.3.2)
The delimiter information requires one more character. Therefore one more byte is added
after Position No.13 in the above example. Consequently, the data becomes 1 byte longer.
(3) Data format in case of “oL” or “-oL” (Overload)
The below is the data format for “oL”.
Data length of this example: 13 bytes
Position 1 2 3 4 5 6 7 8 9 10 11 12 13
ASCII
code
20H 20H 20H 20H 20H 4FH 4CH 20H 20H 20H 20H 20H 0DH
Data O L C/R
For “-oL” (negative overload), Position 1 is replaced with “-” (minus, ASCII code: 2DH).
The following parts appearing in “(2) Information of additional bytes” also apply to (3).
(i) Output with stability information
(iii) When the delimiter “C/R+L/F” is selected
