SECTION 3 − DUTY − INDUSTRIAL APPLICATION
72
MOTORI
ED. FEBUARY 2003
COMPONENT TORQUE
Nm kgm
Rear lifting bracket (M12x1.75x30) 77 ± 12 7.7 ± 1.2
Crankshaft pulley (M12x1.75x10.9) 110 ± 5 11.0 ± 0.5
Flywheel housing
(M12x120)
(M12x80)
(M10x80)
(M10x40)
85 ± 10
85 ± 10
49 ± 5
49 ± 5
8.5 ± 1.0
8.5 ± 1.0
4.9 ± 0.5
4.9 ± 0.5
Flywheel housing (M12x1.25) 1st stage 30 ± 4 3.0 ± 0.4
2nd stage 60º ± 5º
Assy rear cover plate to flywheel housing (M8x1.25x16)
24 ± 4 2.4 ± 0.4
Fuel injectors 60 ± 5 6.0 ± 0.5
Fuel lift pump 24 ± 4 2.4 ± 0.4
Turbocharger to exhaust manifold (M10) 43 ± 6 4.3 ± 0.6
Oil feed to oil filter head 24 ± 4 2.4 ± 0.4
Oil feed to turbocharger (M12x1.5) 35 ± 5 3.5 ± 0.5
Oil drain (M8x1.25x16) 24 ± 4 2.4 ± 0.4
Alternator to alternator support (M8x1.25x30) 24 ± 4 2.4 ± 0.4
Alternator to water inlet conn. assy (M8x1.25x30) 24 ± 4 2.4 ± 0.4
Lower alternator mounting (M10x1.25x25) 24 ± 4 2.4 ± 0.4
Alternator upper pivot to support (M10) 49 ± 5 4.9 ± 0.5
Alternator mounting hardware (M12x1.75x120) 43 ± 6 4.3 ± 0.6
Alternator wiring (M6x1.0 nut) 10 ± 2 1.0 ± 0,2
Starter motor to gear case (M10) 49 ± 5 4.9 ± 0.5
