Data, features and performances are valid only if the setter fully complies with all the installation prescriptions.
Furthermore, the users assembled by the setter shall always be in conformance to couple, power and number of turns
based on which the engine has been designed.
SECTION 3 – DUTY – INDUSTRIAL APPLICATION
4
NEF ENGINES
ED. FEBRUARY 2003
CLEARANCE DATA – 4 CYL.
F4GE04
Type
04A*D6 54A*D6 84C*D6
Compression ratio
17 : 1
Max. output kW
(HP)
rpm
60
81
2300
74
100
2300
94
128
2300
Max. torque Nm
(kgm)
rpm
–
–
–
398
39.8
1400
Loadless engine
idling rpm
850 850 850
Loadless engine
peak rpm
2300 2300 2300
SUPERCHARGING
Turbocharger type
with intercooler
HOLSET HX27W
bar
LUBRICATION
Oil pressure (warm engine)
– idling bar
– peak rpm bar
Forced by gear pump, relief valve single action
oil filter
0.70
3.50
COOLING
Water pump control
Thermostat
– start of opening ºC
By centrifugal pump, regulating thermostat, heat
exchanger, intercooler
Through belt
15W40 ACEA E3
FILLING
engine sump liters
engine sump + filter liters
500
50.0
1400
Bore x stroke mm
Displacement cm
104 x 132
4485
±
81 2
8.5
9.5
