Case 445/M2 - SECTION 3 - DUTY - INDUSTRIAL EQUIPMENT

SECTION 3 − DUTY − INDUSTRIAL APPLICATION E NG I NE S
1
ED. FEBUARY 2003
HYDRAULIC SYSTEM − BRAKES
SECTION 3
DUTY − INDUSTRIAL
EQUIPMENT
Pagina
GENERAL INFORMATION 3
- Version equipped with mechanical feed pump 3
- Clearance data 4
PART ONE − MECHANICAL COMPONENTS 7
OVERHAUL OF ENGINE PROVIDED WITH
MECHANICAL ROTARY PUMP 9
- Preface 9
- Engine setting operations for the assembly on
turning stand 9
- Disassembly of application components 11
- Installation of application components 19
- Completion of the engine 33
- Rotary feed pump disassembly and
assembly procedure 35
- Feed system bleed procedure 38
- Power take−off disassembly and assembly
procedure 38
- Check and controls 38
OVERHAUL OF ENGINE PROVIDED WITH
MECHANICAL IN LINE PUMP 39
- Preface 39
- Engine setting operations for the assembly on
turning stand 39
- Disassembly of application components 41
- Installation of application components 49
- Completion of the engine 63
- Feed pump unit disassembly and
assembly procedure 65
- Feed system bleed procedure 69
- Power take−off disassembly and assembly
procedure 69
- Check and controls 69
TIGHTENING TORQUE 71
