Case 445/M2 - Clearance Data

SECTION 4 − OVERHAUL AND TECHNICAL SPECIFICATIONS
4
ENGINES
ED. FEBUARY 2003
CLEARANCE DATA
Ty p e 4CYLINDERS 6CYLINDERS
CYLINDER UNIT AND CRANKSHAFT COMPONENTS mm
∅
1
X
Cylinder barrels ∅1
104.000 to1 04.024
L
∅
Cylinder bar rels:
outside diameter ∅ 2
length L
−
−
Cylinder barrels — housings on
engine block (interference)
−
Outside diameter ∅ 2 −
∅
3
X
Cylinder barrels:
inside diameter ∅ 2
−
∅
1
X
∅
2
Spare pistons
type:
Size X
Outside diameter ∅ 1
Pin housing ∅ 2
55.9
103.730 to103.748
38.010 to 38.016
Piston — cylinder barrels 0.252 to 0.294
Piston diameter ∅ 1 0.5
X
Piston protrusion X 0.28 to 0.42
3
∅
Piston pin ∅ 3 38.000 to 38.006
Piston pin — pin housing 0.004 to 0.016
