Case 445/M2 - TIGHTENING TORQUE

SECTION 4 − OVERHAUL AND TECHNICAL SPECIFICATIONS
36
ENGINES
ED. FEBUARY 2003
TIGHTENING TORQUE
COMPONENT TORQUE
Nm kgm
Screw M8 for fastening cylinder barrel lubricating nozzles 15 ± 3 1.5 ± 0.3
Screw M12 for fastening output shaft caps 1
st
stage
2
nd
stage
d
50 ± 6
80 ± 6
5 ± 0.6
8 ± 0.6
2
s
t
a
g
e
3
rd
stage
90º ± 5º
Screw M8 for fastening camshaft longitudinal retaining plate
24 ± 4 2.4 ± 0.4
Screw M8 for fastening camshaft gear 36 ± 4 3.6 ± 0.4
Screw M11 for fastening connecting rod caps 1
st
stage
d
60 ± 5 6 ± 0.5
S
c
r
e
w
M
1
1
f
o
r
f
a
s
t
e
n
i
n
g
c
o
n
n
e
c
t
i
n
g
r
o
d
c
a
p
s
1
s
t
a
g
e
2
nd
stage
60º ± 5º
