3244t
1. Fuel filter bearing− 2. Heater − 3. Water dump screw− 4. Filter cartridge −
5. Temperature sensor
FUEL FILTER
Th e filter is assembled c lose to th e feed an d pr imin g pu mp an d h as th e spec ific du t y t o provide bar r ier to th e impu r ities an d separ a-
tion of water from fuel.
O n th e filter c ar t r idge base (4) th ere is a water du mp sc rew, t h rou gh ou t w h ic h it is po ssible t o provide regu lar dr ain age; o n t h e
bear in g (1) for t h o se equ ipmen t applic ation s requ ir in g it (c o ld c limate areas), th ere c an be a h eater assembled t o (2) an d a temper a-
t u re sen s o r (5).
1
3
4
1
2
5
4
3
3243t
Figura 5
E NG I NE S SECTION 2 − FEED 7
ED. FEBUARY 2003
