Figure 1
F4BE0484 engines have been designed and developed
spec i fi c al ly for tr anspor tati on by l and and f ar mi ng
equipment in general.
They are featured by 4 stroke diesel cycle having 4 cylinder
boost with 2 valves per cylinder.
Feed is provided by rotary mechanical pump or on line
according to the equipment application.
It differ s from other applications because of the provision of
different power, power take−off for the different collector
configuration, priming pump, oil pan and boost turbine.
The section herein described is composed or four directories:
- directory of mechanical overhaul prescribed in
accordance to the engine’s specific duty, illustrating all
necessary operations to remove and assembly the
external components of the engine, including cylinder
heads, gearbox of the timing system and of the front part
cover;
- electrical directory, describing the connections of the
different components, of the pre−post heating gearbox
(only for some versions) and of the sensors assembled to
the engine;
- troubleshooting directory;
- directory of preventive and regular maintenance
operations, providing instructions for the execution of the
main operations.
Version equipped with mechanical feed pump
!
The picture shows application designed for 4 cylinders
version, 2 valves per cylinder, having fuel feed
mechanical pump .
03220t
!
Data, technical specifications and performances
granted shall be valid only if the Setter will follow and
c o mply wi th al l i nstal l ati on pr esc r i pti ons.
Furthermore, the expanders assembled by the Setter
must always comply with couple, power and number
of revolutions based on which the engine has been
designed.
SECTION 3 − DUTY − INDUSTRIAL APPLIC ATION
ENGINES 3
ED. FEBUARY 2003
GENERAL INFORMATION
