APPENDIX
Bottom
bs
Speaker (page 161)
bt
Tripod Hole
Use this hole when attaching to a tripod.
ck
Cradle Contact (page 39)
cl
Battery/Memory Card Slots (pages 37, 49)
■ USB Cradle
Front
Back
clbs bt ck
1
Camera Contact (page 39)
2
USB Lamp
(pages 237, 253, 274)
3
[USB] Button
(pages 223, 237, 253)
4
[PHOTO] Button
(pages 169, 171)
5
[CHARGE] Lamp
(pages 39, 274)
6
[AV OUT] (AV output port)
(page 170)
7
[ ] (USB) Connector
(pages 221, 236, 252)
8
[DC IN 5.3V] (External
Power) Terminal (page 38)
