116
8 - 2 View Window (V-Window) Settings
kk
kk
k View Window Memory
You can store up to six sets of View Window settings in View Window memory for
recall when you need them.
uu
uu
uTo store View Window settings
Inputting View Window values and then pressing 4 (STO) 1 (V·W1) stores the
View Window contents in View Window memory V·W1.
• There are six View Window memories numbered V·W1 to V·W6.
•Storing View Window settings in a memory area that already contains settings
replaces the existing settings with the new ones.
uu
uu
uTo recall View Window settings
Pressing 5 (RCL) 1 (V·W1) recalls the contents of View Window memory
V·W1.
•Recalling View Window settings causes the settings currently on the display to
be deleted.
•You can change View Window settings in a program using the following
syntax.
View Window [X min value], [X max value], [X scale value],
[Y min value], [Y max value], [Y scale value],
[T,
θ
min value], [T,
θ
max value], [T,
θ
pitch value]
To Next Page
