146
Search for the next root to the right.
e
• If there is no root to the right, nothing
happens when you press e.
e
•You can use d to move back to the left.
• If there is only one graph, pressing 1(ROOT) directly displays the root
(selection of the graph is not required).
•Note that the above operation can be performed on rectangular coordinate
(Y=) and inequality graphs only.
kk
kk
k Determining Local Maximum Values and Local Minimum
Values
Example To determine the local maximum value and local minimum
value for y = x (x + 2) (x – 2)
View Window: (A)
!5(G-Solv)
2(MAX)
(This puts the unit into standby waiting
for selection of a graph.)
Specify the graph and determine the local maximum value.
cw
9 - 2 Analyzing a Function Graph
