3 GENERAL DESCRIPTIONS
This welding machine is an inverter power source. It is suitable for TIG welding with contact ignition and high frequency,
and for MMA welding with the exception of cellulosic electrodes. The power source is built according to IEC 60974-1,
IEC 60974-3, IEC 60974-10 (CL. A), IEC 61000-3-11 and IEC 61000-3-12 standards.
3�1 Explanation of plate data
No.
Serial number, to be indicated on any request regarding the welding machine.
1
Single-phasestaticfrequencyconvertertransformer-rectier.
3
Three-phasestatictransformer-rectierfrequencyconverter.
MMA Suitable for welding with coated electrodes.
TIG Suitable for TIG welding.
U0 Secondary open-circuit voltage.
X
Duty cycle percentage. The duty cycle expresses the percentage of 10 minutes during which
the welding machine can run at welding current I2.
Up
High-frequency ignition voltage for TIG process.
U2
Secondary voltage with I2 current.
U1
Rated supply voltage.
1~ 50/60Hz
50 or 60-Hz single-phase power supply.
3~ 50/60Hz 50 or 60-Hz three-phase power supply.
I
1max
Max. current absorbed at the corresponding current I
2
and voltage U
2
.
I
1e󰀨
This is the maximum value of the actual current consumed, considering the duty cycle. This
value usually corresponds to the capacity of the fuse (delayed type) to be used as a protection
for the equipment.
IP23S
Degree of housing protection.
Grade 3 as the second digit means that this machine may be stored, but it is not suitable for
use outdoors in the rain, unless it is protected.
Device suitable for use in locations with increased electrical risk
3�2 Environmental conditions
Room air temperature range:
−in working conditions: -10°C to +40°C (14°F to 104°F)
−in transport or storage conditions: -20°C to 55°C (-4°F to 131 °F)
Air relative humidity:
−upto50%at40°C(104°F)
−upto90%at20°C(68°F)
Altitude above sea level:
−up to 1000 m (3281 ft.)
Room air:
−without excessive amounts of dust
−acid free
−free from corrosive gases
−Angleofweldingmachinesupportbaseupto10%
