Cebora 553 - Accessories (for Item no 555 and 557 Only); Measuring System (Only for Item no 558)

78/89
Table 7
Description Min Def Max UM Sol�
H00 IH1
Amplitude of hot-start starting current
(ignition with HF)
0 120 300 A 1
H01 IH2
Amplitude of hot-start second current
(ignition with HF)
10 40 100 A 1
H02 tH2
Duration of hot-start second current
(ignition with HF)
0 7 250 ms 1
H03 SLO
Gradientofhotstartttingwithstartingwelding
current
1 2 100 A/ms 1
H04 IL1 Amplitude of hot-start current (ignition striking/lift) 5 25 100 A 1
H05 tL1 Duration of hot-start current (ignition striking/lift) 0 150 200 ms 1
H06 LCK Panel setting lock down (free, total, partial) PARTIAL FREE TOTAL - -
H08 UDJ
UP/DOWN handling during JOBS
(OFF=not activated, 1=without roll, 2=with roll)
OFF OFF 2 - 1
H09 LIM Currentlevelrangeextensionupto400% 100 100 400 % -
H10 TPH Phase detection (For Item No 555 and 557 only) ON ON OFF - -
7�2�5 Accessories (For Item No 555 and 557 only)
COOLING UNIT
For Item No 557 and 555 only
PressknobBtoselectthecoolingunitoperatingmodeandconrm.
Return to the previous page, or press and hold knob B (> 0.7 sec.) to
return to the main screen.
7�2�6 Measuring system (only for Item No 558)
The measuring system can be selected for Item No 558
